KEMET Engineering Sortiment
| Bild | Produkt | Preis | Anzahl | Warenkorb |
| KEMET Engineering Sortiment
- T520: 14 Werte - A700: 14 Werte - High Capacitance: 13 Werte - FlexDesign: 28 Werte - 5/10/20/40 Stk. pro Wert - Kemet Produkt-ID: KEMET-TACC |
305,00 EUR zzgl. 19% USt. zzgl. Versandkosten |
| Bild1 | Bild2 | Bild3 |
 |
 |
|
| Datasheets |
KEMET Engineering Sortiment(KEMET Sample Kit.pdf, 5085 KB)
Februar 2010 download
| Bauteile technische Daten Components technical specifications |
|
Bezeichnung Parameter |
Wert Value |
Einheit Unit |
|
Bauteilgröße Component size |
- | |
|
Hersteller Manufacturer |
KEMET | |
|
Bauteilserie Component series |
High Capacitance/FlexDesign/T520/A700 | |
|
Bauteiltoleranz Tolerance of the components |
Siehe Tabelle: "Sortiment Inhalt" See table: "Sample Kit Content" |
| Eigenschaften des Sortiments Characteristics of the sample kit |
|
Bezeichnung Parameter |
Wert Value |
Einheit Unit |
|
Bauteilgröße Component size |
- | |
|
Bauteiltoleranz Tolerance of the Components |
Siehe Tabelle: "Sortiment Inhalt" See table: "Sample Kit Content" |
|
|
Wertebereich Range of values |
220pF - 1000uF | |
|
IEC-Reihe IEC standart |
- | |
|
Anzahl der Werte Number of values |
69 | |
|
Bauteile pro Wert Number of parts per value |
5/10/20/40 |
Stück pieces |
|
Bauteile gesamt Number of parts in total |
1570 |
Stück pieces |
|
RoHS konform RoHS Compliance |
Ja Yes |
|
|
Sortimentsystem Sample kit system |
A4 Ringordner A4 ring binder |
|
|
Abmessungen (L x B x H) Dimensions (l x w x h) |
ca. / approx. 320 x 285 x 50 | mm |
|
Gewicht Weight |
1,2 | kg |
|
Seitenanzahl PET-Flachpackung Number of pages |
5 |
Stück pieces |
| Inhalt KEMET Tantalum Surface Mount Organic T520 Sortiment KEMET Tantalum Surface Mount Organic T520 Sample Kit Content |
|
Nr. Nbr. |
Wert/Value |
Size Code |
Spannungs-festigkeit Rated voltage |
Toleranz Tolerance |
Herstellernummer (7 Zoll Bauteilrolle) Ordering Code (7 inch dia. Reel) |
| 1 | 470uF | V | 2 Vdc | +-20% | T520V477M002ATE040 |
| 2 | 100uF | T | 2,5 Vdc | +-20% | T520T107M2R5ATE070 |
| 3 | 220uF | W | 2,5 Vdc | +-20% | T520W227M2R5ATE025 |
| 4 | 470uF | V | 2,5 Vdc | +-20% | T520V477M2R5ATE007 |
| 5 | 1000uF | D | 2,5 Vdc | +-20% | T520D108M2R5ATE030 |
| 6 | 680uF | Y | 4 Vdc | +-20% | T520Y687M004ATE010 |
| 7 | 470uF | Y | 6 Vdc | +-20% | T520Y477M006ATE010 |
| 8 | 150uF | D | 10 Vdc | +-20% | T520D157M010ATE015 |
| 9 | 150uF | D | 10 Vdc | +-20% | T520D157M010ATE018 |
| 10 | 150uF | Y | 10 Vdc | +-20% | T520Y157M010ATE018 |
| 11 | 330uF | X | 10 Vdc | +-20% | T520X337M010ATE010 |
| 12 | 68uF | D | 16 Vdc | +-20% | T520D686M016ATE050 |
| 13 | 22uF | V | 20 Vdc | +-20% | T520V226M020ATE040 |
| 14 | 15uF | D | 25 Vdc | +-20% | T520D156M025ATE060 |
| Inhalt Aluminum Organic Polymer Chip A700 Sortiment Aluminum Organic Polymer Chip A700 Sample Kit Content |
|
Nr. Nbr. |
Werte/ Value |
Size Code |
Spannungs-festigkeit Rated voltage |
Toleranz Tolerance |
Herstellernummer (7 Zoll Bauteilrolle) Ordering Code (7 inch dia. Reel) |
| 1 | 330uF | D | 2 Vdc | +-20% | A700D337M002ATE007 |
| 2 | 470uF | X | 2 Vdc | +-20% | A700X477M002ATE007 |
| 3 | 220uF | X | 2,5 Vdc | +-20% | A700X227M2R5ATE010 |
| 4 | 220uF | D | 4 Vdc | +-20% | A700D227M004ATE009 |
| 5 | 330uF | X | 4 Vdc | +-20% | A700X337M004ATE010 |
| 6 | 100uF | V | 6 Vdc | +-20% | A700V107M006ATE015 |
| 7 | 150uF | D | 6 Vdc | +-20% | A700D157M006ATE010 |
| 8 | 180uF | X | 6 Vdc | +-20% | A700X187M006ATE010 |
| 9 | 100uF | X | 8 Vdc | +-20% | A700X107M008ATE010 |
| 10 | 150uF | X | 10 Vdc | +-20% | A700X157M010ATE010 |
| 11 | 100uF | X | 12 Vdc | +-20% | A700X107M012ATE015 |
| 12 | 22uF | V | 12,5 Vdc | +-20% | A700V226M12RATE030 |
| 13 | 47uF | D | 12,5 Vdc | +-20% | A700D476M12RATE025 |
| 14 | 22uF | D | 16 Vdc | +-20% | A700D226M016ATE025 |
| Inhalt KEMET High Capacitance Sortiment KEMET High Capacitance Sample Kit Content |
|
Nr. Nbr. |
Wert/Value |
Dielektrikum Dielectric- material |
Spannungs-festigkeit Rated voltage |
Toleranz Tolerance |
Herstellernummer (7 Zoll Bauteilrolle) Ordering Code (7 inch dia. Reel) |
| 1 | 3,3uF | X5R | 4 Vdc | +-20% | C0402C335M7PAC |
| 2 | 4,7uF | X5R | 4 Vdc | +-20% | C0402C475M7PAC |
| 3 | 47uF | X5R | 4 Vdc | +-20% | C0805C476M7PAC |
| 4 | 2,2uF | X5R | 6,3 Vdc | +-20% | C0402C225M9PAC |
| 5 | 10uF | X5R | 6,3 Vdc | +-20% | C0603C106M9PAC |
| 6 | 47uF | X5R | 6,3 Vdc | +-20% | C1206C476M9PAC |
| 7 | 100uF | X5R | 6,3 Vdc | +-20% | C1210C107M9PAC |
| 8 | 22uF | X5R | 10 Vdc | +-20% | C1206C226M8PAC |
| 9 | 22uF | X7R | 16 Vdc | +-10% | C2220C226K4RAC |
| 10 | 47uF | X5R | 16 Vdc | +-20% | C1210C476M4PAC |
| 11 | 4,7uF | X5R | 50 Vdc | +-20% | C1206C475M5PAC |
| 12 | 2,2uF | X7R | 50 Vdc | +-10% | C1825C225K5RAC |
| 13 | 2,2uF | X7R | 100 Vdc | +-20% | C1210C225M1RAC |
| Inhalt KEMET FlexDesign Sortiment KEMET FlexDesign Sample Kit Content |
|
Nr. Nbr. |
Wert/Value |
Technologie Technology |
Spannungs-festigkeit Rated voltage |
Toleranz Tolerance |
Herstellernummer (7 Zoll Bauteilrolle) Ordering Code (7 inch dia. Reel) |
| 1 | 200pF | Floating Electrode | 200 Vdc | +-5% | C0603S221J2RAC |
| 2 | 2,2nF | Floating Electrode | 200 Vdc | +-5% | C0603S222J2RAC |
| 3 | 4,7nF | Floating Electrode | 200 Vdc | +-5% | C0603S472J2RAC |
| 4 | 22nF | Floating Electrode | 100 Vdc | +-10% | C0805S223K1RAC |
| 5 | 22nF | Open Mode | 25 Vdc | +-10% | C0805F223K3RAC |
| 6 | 47nF | Floating Electrode | 50 Vdc | +-10% | C0805S473K5RAC |
| 7 | 47nF | Open Mode | 25 Vdc | +-10% | C0805F473K3RAC |
| 8 | 47nF | Flexible Termination | 100 Vdc | +-10% | C0603X473K1RAC |
| 9 | 56nF | Floating Electrode | 50 Vdc | +-10% | C1210S563K5RAC |
| 10 | 100nF | Floating Electrode | 50 Vdc | +-10% | C0805S104K5RAC |
| 11 | 100nF | Open Mode | 25 Vdc | +-10% | C0805F104K3RAC |
| 12 | 120nF | Flexible Termination | 200 Vdc | +-10% | C1206X124K2RAC |
| 13 | 220nF | Open Mode | 25 Vdc | +-10% | C0805F224K3RAC |
| 14 | 220nF | Flexible Termination | 100 Vdc | +-10% | C0805X224K1RAC |
| 15 | 470nF | Open Mode | 25 Vdc | +-10% | C0805F474K3RAC |
| 16 | 470nF | Flexible Termination | 16 Vdc | +-10% | C0603X474K4RAC |
| 17 | 470nF | Flexible Termination | 50 Vdc | +-10% | C0805X474K5RAC |
| 18 | 470nF | Flexible Termination | 100 Vdc | +-10% | C1206X474K1RAC |
| 19 | 1uF | Flexible Termination | 25 Vdc | +-10% | C0805X105K3RAC |
| 20 | 1uF | Flexible Termination | 100 Vdc | +-10% | C1210X105K1RAC |
| 21 | 2,2uF | Open Mode | 16 Vdc | +-10% | C1206F225K4RAC |
| 22 | 2,2uF | Flexible Termination | 16 Vdc | +-10% | C0805X225K4RAC |
| 23 | 2,2uF | Flexible Termination | 50 Vdc | +-10% | C1206X225K5RAC |
| 24 | 4,7uF | Open Mode | 16 Vdc | +-10% | C1206F475K4RAC |
| 25 | 4,7uF | Flexible Termination | 25 Vdc | +-10% | C1206X475K3RAC |
| 26 | 4,7uF | Flexible Termination | 50 Vdc | +-10% | C1210X475K5RAC |
| 27 | 10uF | Flexible Termination | 16 Vdc | +-10% | C1206X106K4RAC |
| 28 | 10uF | Flexible Termination | 25 Vdc | +-10% | C1210X106K3RAC |
